Cormak 24T Transport Skates Set

Cormak 24Ton Transport Skate Set

Total Load Capacity (WL12 & WF12): 24T

Description A set of transport rollers consisting of a WL12 mobile platform and a WF12 transport chassis. The maximum lifting capacity of the set is 24 tons. Transport rollers enable easy and safe transport of heavy objects. Thanks to the use of polyurethane thread rollers the transported machine and the floor are not damaged. Technical Details - WL12

Rollers size: 85mm

Number of rolls: 16

Capacity: 12000kg

Loading Height: 110mm

Load Bearing Surface: Ø 170mm

Supporting Points: 1

Length of Shaft: 1080mm

Turning Angle of Shaft: ± 90 Degree

Dimensions: 1030 x 620 x 110mm

Weight: 80 kg Technical Details - WF12

Rollers size: 85mm

Number of rollers: 16

Capacity: 12000kg

Loading Height: 110mm

Load Bearing Surface: 200 x 407mm

Supporting Points: 2

Connector Length: 1430mm

Width distribution of skates: 1014-1430mm

Weight: 52kg
