2000 Meiki M-50C-AS-DM Injection Moulding Machine
Sold
Description
2000 Meiki M-50C-AS-DM Injection Moulding Machine
Machine Type: 50 Ton Injection Moulding Machine
Year: 2000
Condition: Good - Decommissioned
Technical Specifications
Screw Diameter: 22mm
Injection Pressure: 250MPa
Injection Capacity: 34cm3
Clamping Force: 495kN
Max Mould Size: 460 x 310mm
Closing Stroke: 390mm
Min Mould Height: 140mm
Heating Capacity: 6.9kW
Motor Capacity: 15kW
Injection Hydraulic Pressure: 10.8MPa
Clamping Hydraulic Pressure: 14.0MPa
Screw Driving Pressure: 13.7MPa
Machine Weight: 2500kg
Specifications
| Manufacturer | Meiki |
| Model | M-50C-AS-DM Injection Moulding Machine |
| Year | 2000 |
| Condition | Used |
| Year | 2000 |
| Screw Diameter | 22mm |
| Injection Pressure | 250MPa |
| Injection Capacity | 34cm3 |
| Clamping Force | 495kN |
| Max Mould Size | 460 x 310mm |
| Closing Stroke | 390mm |
| Min Mould Height | 140mm |
| Heating Capacity | 6.9kW |
| Motor Capacity | 15kW |
| Injection Hydraulic Pressure | 10.8MPa |
| Clamping Hydraulic Pressure | 14.0MPa |
| Screw Driving Pressure | 13.7MPa |
| Machine Weight | 2500kg |
